ZoneFlex R730 802.11 abgn/ac/ax indoor AP, supporting 2.4GHz (4x4:4) and 5GHz (8X8:8), OFDMA, MU-MIMO, multi-rate Gigabit interface 1X2.5G/5Gbps Ethernet interface, 1X10/100 /1000Mbps Ethernet port, PoH/uPoE/802.3at POE. Does not include power adapter and POE module
Văn Phòng Công Ty
-
HO CHI MINH Văn Phòng Chính: 134/8 Hoàng Hoa Thám, Phường 12, Quận Tân Bình. HCM
-
HO CHI MINH Kho Quận 7: 14 Đường số 1, Phường Bình Thuận, Quận 7, HCM
-
VĂN PHÒNG HÀ NỘI: 18/521 Nguyễn Trãi.Thanh Xuân Nam.Thanh xuân .Hà nội
Features and Benefits
The R730 is based on the latest Wi-Fi standard, 802.11ax and bridges the performance gap from ‘gigabit’ Wi-Fi to ‘multi-gigabit’ Wi-Fi in support of the insatiable demand for better and faster Wi-Fi.
The R730 makes it easy to deliver reliable, secure, high-performance connectivity in large enterprises, small & medium businesses, public venues, convention centers, and practically any other indoor space.
The RUCKUS R730 is our highest capacity dual-band, dual-concurrent 802.11ax AP that supports 12 spatial streams (8x8:8 in 5GHz, 4x4:4 in 2.4GHz). The R730, with OFDMA and MU-MIMO capabilities, efficiently manages more than 1K client connections with increased capacity, improved coverage and performance in ultra-high dense environments. Furthermore, 5 Gbps multi-gigabit Ethernet ports enhances backhaul capacity.
The R730 is also easy to manage through RUCKUS’ appliance, virtual and cloud management options.
Specifications
General Specifications
| Antenna Gain | Up to 2 dBi |
| Antenna Patterns, per band | 4000+ |
| BeamFlex | Yes |
| ChannelFly | Yes |
| Concurrent Users | 1024 |
| Controller Support | SmartZone | Standalone | ZD |
| Ethernet Ports | 1x 1/2.5/5 Gb/s | 1x 10/100/1000 Mb/s |
| IoT Ready | Yes |
| PD-MRC | Yes |
| PHY Rate at 2.4 GHz, maximum | 1148 Mb/s |
| PHY Rate at 5 GHz, maximum | 4800 Mb/s |
| Radio Chains:Streams | 8x8:8 SU-MIMO & MU-MIMO |
| Rx Sensitivity at 2.4 GHz | -103 dBm |
| Rx Sensitivity at 5 GHz | -101 dBm |
| SmartMesh | Yes |
| USB | USB 2.0 |
| Venue Type | Education | Hospitality | Public Venue |
| Venue Sub-Type | Cafeteria/Multipurpose Room | Convention Floor | Lecture Hall | Library | Venue Common Places |
| Wi-Fi Interface Standard | IEEE 802.11a/b/g/n/ac/ax |
| Wi-Fi Interface Standard at 2.4 GHz | 802.11ax |
| Wi-Fi Interface Standard at 5 GHz | 802.11ax |
Environmental Specifications
| Operating Temperature | 0 °C to +50 °C (+32 °F to +122 °F) |
Specifications:
| ||||
|---|---|---|---|---|
|  |  |  |  |
Feature/Description | High-end 802.11ax 4x4 dual concurrent AP with MU-MIMO, BeamFlex+ and 2.5Gbps backhaul | High-end 802.11ax 8x8 dual concurrent AP with MU-MIMO, BeamFlex+ and 5Gbps backhaul | High-end 802.11ac Wave 2 dual- concurrent AP with MU-MIMO BeamFlex+ and 2.5Gbps backhaul | High-end 802.11ac Wave 2 dual- concurrent AP with MU-MIMO and BeamFlex+ |
Maximum PHY rate | 2400 Mbps (5GHz) 1148 Mbps (2.4GHz) | 4800 Mbps (5GHz) 1148 Mbps (2.4GHz) | 1733 Mbps (5GHz) 600 Mbps (2.4GHz) | 1733 Mbps (5GHz) 600 Mbps (2.4GHz) |
Wi-Fi technology | 802.11ax (2.4GHz, 5GHz) Wi-Fi CERTIFIED 6™ |
802.11ax (2.4 GHz, 5GHz) | 802.11ac (5GHz) 802.11n (2.4GHz) | 802.11ac (5GHz) 802.11n (2.4GHz) |
Concurrent users | 1024 | 1024 | 512 | 512 |
Radio chains:streams |
4x4:4 |
8x8:8 |
4x4:4 | 4x4:4 SU-MIMO 4x4:3 MU-MIMO |
Antenna patterns (per band) | 4,000+ | 4,000+ | 4,000+ | 4,000+ |
Antenna gain | Up to 3dbi | Up to 2dBi | Up to 3dBi | Up to 3dBi |
PD-MRC | ||||
Rx sensitivity (2.4/5GHz) | -102dBm | -103/-101dBm | -104dBm | -104dBm |
ChannelFly | ||||
SmartMesh | ||||
USB (IoT Ready) | ||||
Ethernet ports | 1x1GbE 1x2.5GbE | 1x 1/2.5/5 Gbps 1x 10/100/1000 Mbps | 1 x 1GbE and 1 x 2.5GbE |
2 x 1GbE |
Integrated BLE/ZigBee | — | — | ||
WLAN Control and Management | · ZoneDirector · SmartZone · Unleashed · RUCKUS Cloud | · ZoneDirector · SmartZone · RUCKUS Cloud | · ZoneDirector · SmartZone · Unleashed · RUCKUS Cloud | · ZoneDirector · SmartZone · Unleashed · RUCKUS Cloud |
