- LoRaWAN Class A compatible
- Frequency Hopping Spread Spectrum (FHSS)
- Improved interference immunity
- Improved power management for longer battery life
- Battery Life*2:
- Please refer to web: http://www.netvox.com.tw/electric/electric_calc.html
- At this website, users can find battery life time for varier models at different configurations.
- Over-the-air updates (future)
- Third-Party online wireless sensor monitoring and notification system to configure sensors, view data and set alerts via SMS text and email (optional)
- Available third-party platform: Actility/ThingPark, TTN, MyDevices/Cayenne
*1. Actual range may vary depending on environment.
*2. Battery life is determined by sensor reporting frequency and other variables
Electric:
Input Power | 2pcs 3.0V CR2450 button battery |
Working Voltage | DC 2.4V～3.0V |
Standby Current | 16uA /3.0V |
Transmitting Current (max) | 120mA / 3.0V |
Receiving Current (max) | 11mA / 3.0V |
Battery Voltage Measurement Accuracy | ±0.1V |
Frequency:
Frequency Range | 863MHz-928MHz 470MHz-510MHz |
TX Power | 19dBm±1dBm |
Rx Sensitivity | -136dBm |
Antenna Type | Build-in antenna |
Communication Range | Up to10 km, the actual transmission distance depends on the environment. |
Data Transfer Rate | 0.3kbps～50kbps |
Spread Technique | LoRa/FSK |
Available Frequency | EU863-870，US902-928，AU915-928， |
Physical:
Main Body Dimension | 57mm x 35mm x 15.2mm |
Weight | 48.9 g |
Operating Temperature | -20℃ ～ 55℃ |
Environment Humidity Range | <90% RH (No condensation) |
Storage Temperature | -40℃ ～ 85℃ |
