Thiết bị định vị LoraWAN GPS Tracker - LW001-BG

LoRaWAN GPS Tracker: LW001-BG is based on standard LoRaWAN protocol for assets tracking, which built-in GPS & 9-Axis Motion Tracking sensor. Ideal to optimize (intra-) logistic process in the field of container- and asset management, warehouse and inventory scenarios, outdoor tracking, theft protection and much more. In a definable interval, LW001-BG automatically reports its identification number, movement and acceleration data as well as the position. Moko also could provide customized service to suit your application scenarios.

* Based on LoRaWAN™ Protocol
* Support GPS positioning with accuracy within 2.5m CEP
* Built-in 9-Axis motion tracking sensor, support moving object detection
* Support for configuring ABP and OTAA modes with MokoLora APP
* Firmware update Over The Air (OTA)
* Support a wide range frequency CN470MHZ EU868MHZ AU915MHZ US915MHZ AS923MHZ
* 4000mAh non-chargeable battery
* Ultra Low Power，Max. 5-year operating time (Data are reported twice a day)
* Low battery indicator.

asset management tracking and location; Smart animal farming Management;
Logistica and supply chain management; Smart cities Management;
Safety of people and objects;
Smart factory Industrial Management etc.

User Case

* Connexin use our LoRaWAN GPS tracker for their fleet tracking.

In a large fleet, non-powered vehicles will be misplaced, misused or even disappear.
A LoRaWAN GPS tracker from MOKO solves these issues.
With an extremely simple installation, the sensor is attached to the vehicles using military-grade magnets and takes about 1 minute to interface with a computer; then The sensor is active, and it transmits via LoRa, real-time data that indicates if the vehicle is on, off, or idling and its GPS position. A locally installed LoRaWAN gateway listens for the encrypted device transmission and routes the data to the Network Server (eg. TTN) via an internet connection (4G, Wifi, Ethernet, etc.). As the device is already provisioned on the Network Server, the server authenticates, authorises and routes the encrypted device data to the application server.

Not only do you have the security that everything is in its right place, you have the complete daily visibility to save time looking for available rail cart, trailers or containers.
With this knowledge, managers can measure when carts and trailers need a service check-up, saving the time and money of inspections and break downs.

Know where your cattle are

The LoRaWAN GPS Tracker allows you to track and trace your cattle over long distances, even in remote areas without mobile coverage; its sends your cattle's location to provide you with actionable insights and alerts. These insights help you to run a better and more efficient beef enterprise. They are the size of a standard management tag and can be tagged using a normal applicator. The reusable LoRaWAN GPS Tracker is powered with a 4000 mah battery which can last for 5 years.
Its Works in the outback, No need for cellular(2G/3G/4G) coverage from a telco to work as you will have your own network. And its very Easy to apply, This LoRaWAN GPS Tracker use industry standard applicators and female parts which make them easy to apply.
Be ready to Connect your whole property by uses LoRa networks to get the data from the LoRaWAN GPS Tracker. With LoRa (long range) you can transfer data over long distances, especially in a remote areas (8 kilometres line of sight). All you need is an antenna in a location where it has 3G/4G (ideally a hill) or internet from the homestead.
If you have a big property you can easily set up multiple antennas to cover your cattle no matter where they roam.
Moreover, with electric geo-fencing you can Get instant alerts when cattle have jumped the fence or somebody stole your cattle.
