AH-AP-122-AC-W

Loại: Aerohive Indoor AP

Giá: (chưa bao gồm VAT)

Giá so sánh: 5,277,000₫

AP122 2 radio 2x22 WiFi 5 AP 1 GE Ethernet port configurable regulatory domain w/o power supply (Internal Antenna only).AP natively supports 15/16 mount and wall mount. Includes ExtremeCloud IQ Connect HiveCare

1G Port

2x22

802.11ac

WiFi 5

ExtremeCloud IQ Connect Free

1 Year Warranty

Số lượng

Văn Phòng Công Ty

HO CHI MINH Văn Phòng Chính: 134/8 Hoàng Hoa Thám, Phường 12, Quận Tân Bình. HCM

0907771575

(Xem bản đồ)

HO CHI MINH Kho Quận 7: 14 Đường số 1, Phường Bình Thuận, Quận 7, HCM

0987229729

(Xem bản đồ)

VĂN PHÒNG HÀ NỘI: 18/521 Nguyễn Trãi.Thanh Xuân Nam.Thanh xuân .Hà nội

0987229729

(Xem bản đồ)

MIỄN PHÍ VẬN CHUYỂN

THANH TOÁN ĐẢM BẢO

HỖ TRỢ 24/7

HOÀN TRẢ MIỄN PHÍ

Overview:

Enterprise-grade 2x2, 2-stream, 802.11n/ac access point for coverage oriented environments, as well as IoT and location-based services

AP122 provides dual 802.11n or 11n/ac performance with data rates up to 867 Mbps using existing 802.3af PoE infrastructure. Versatile and cost-effective, AP122 is optimally suited for coverage- oriented, low-to medium capacity environments.

Running powerful HiveOS coupled with innovative distributed Cooper - ative Control architecture, AP122 brings the best of coverage and ad - vanced 802.11ac technology. In addition, the integrated BLE radio and a USB interface in the access point opens up a multitude of deployment use-cases in IoT and proximity/location-oriented services.

AP122 is a key component of the Aerohive Connect solution. Connect provides cloud-managed connectivity built on Aerohive’s industry-first co- operative control Wi-Fi focused on optimizing speed and resilience. Con- nect is centrally managed from the cloud, allowing for simple, fast, and powerful management.

Aerohive Connect Components

Enterprise Connectivity

Built-in Bluetooth Low Energy for iBeacon/ other beacon technologies
IoT readiness with USB port
Trusted Platform Module (TPM) – Hardware-based key storage and encryption
Encryption: AES/CCMP, TKIP, and RC4 (WEP only)

Cloud Management

Network Device and Client Monitoring
Global Search and Filter function
Auto-Provisioning Tools for quick and easy deployment
Network Health View
Versatile RF Planning
Guided Network Configuration Setup
802.1X and PSK Secured Networks
Guest Access functionality with configurable Captive Web Portal

Specifications:

Aerohive AP122 Specifications
Radio Specifications—802.11ac 5.150–5.850 GHz Operating Frequency 802.11ac Modulation (256-QAM) Rates (Mbps): MCS0–MCS9 (6.5Mbps – 867 Mbps), NSS = 1-2. 2x2:2 Stream Multiple-In, Multiple-Out (MIMO) Radio VHT20/VHT40/VHT80 support TxBF ( Transmit Beamforming) Radio Specifications—802.11n 2.4–2.5 GHz & 5.150–5.850 GHz Operating 802.11n Modulation Rates (Mbps): MCS0 - MCS15 (6.5MBps - 300Mbps) 2x2 Multiple-In, Multiple-Out (MIMO) Radio Radio Specifications—802.11g 2.4–2.5 GHz Operating Frequency Orthogonal Frequency Division Multiplexing (OFDM) Modulation Rates (Mbps): 54, 48, 36, 24, 18, 12, 9, 6 w/ auto fallback Radio Specifications—802.11b 2.4–2.5 GHz Operating Frequency Direct-Sequence Spread-Spectrum (DSSS) Modulation Rates (Mbps): 11, 5.5, 2, 1 w/ auto fallback Radio Specifications—802.11a 5.150–5.850 GHz Operating Frequency Orthogonal Frequency Division Multiplexing (OFDM) Modulation Rates (Mbps): 54, 48, 36, 24, 18, 12, 9, 6 w/ auto fallback Antennas 2x Integrated single band, 2.4-2.5 GHz Omni- directional antennas 2x Integrated single band, 5.1-5.8 GHz Omni- directional antennas 1 x BLE internal antenna Interfaces Autosensing 10/100/1000 Base-T Ethernet PoE (Power over Ethernet 802.3af) Port RJ-45 console port Standard USB port	Physical LxWxH 171X171X44.5 mm (6.75x6.75x1.75in). w/o mounting brackets Weight: 1.13 lb (0.51 kg) Environmental Operating: 0 to +40°C, Storage: -40 to +70°C Humidity: 95% Environmental Compliance UL2043 Power Specifications IEEE 802.3af PoE Power Power Options Power Draw: Typical 10.5W, Max 12.9W 802.3af / 802.3at (PoE/PoE+) Mounting Desktop Wall Mount Ceiling Tile flush 15/16” Ceiling Tile Recessed 15/16”, 3/8”, 9/16” sold as an accessory Ceiling Tile Flush 3/8”, 9/16” sold as an accessory Suspend Mount sold as an accessory

Aerohive AP122 Specifications

Radio Specifications—802.11ac

5.150–5.850 GHz Operating Frequency
802.11ac Modulation (256-QAM)
Rates (Mbps): MCS0–MCS9 (6.5Mbps – 867 Mbps), NSS = 1-2.
2x2:2 Stream Multiple-In, Multiple-Out (MIMO) Radio
VHT20/VHT40/VHT80 support
TxBF ( Transmit Beamforming)

Radio Specifications—802.11n

2.4–2.5 GHz & 5.150–5.850 GHz Operating
802.11n Modulation
Rates (Mbps): MCS0 - MCS15 (6.5MBps - 300Mbps)
2x2 Multiple-In, Multiple-Out (MIMO) Radio

Radio Specifications—802.11g

2.4–2.5 GHz Operating Frequency
Orthogonal Frequency Division Multiplexing (OFDM) Modulation
Rates (Mbps): 54, 48, 36, 24, 18, 12, 9, 6 w/ auto fallback

Radio Specifications—802.11b

2.4–2.5 GHz Operating Frequency
Direct-Sequence Spread-Spectrum (DSSS) Modulation
Rates (Mbps): 11, 5.5, 2, 1 w/ auto fallback

Radio Specifications—802.11a

5.150–5.850 GHz Operating Frequency
Orthogonal Frequency Division Multiplexing (OFDM) Modulation
Rates (Mbps): 54, 48, 36, 24, 18, 12, 9, 6 w/ auto fallback

Antennas

2x Integrated single band, 2.4-2.5 GHz Omni- directional antennas
2x Integrated single band, 5.1-5.8 GHz Omni- directional antennas
1 x BLE internal antenna

Interfaces

Autosensing 10/100/1000 Base-T Ethernet PoE (Power over Ethernet 802.3af) Port
RJ-45 console port
Standard USB port

Physical

LxWxH 171X171X44.5 mm (6.75x6.75x1.75in). w/o mounting brackets
Weight: 1.13 lb (0.51 kg)

Environmental

Operating: 0 to +40°C, Storage: -40 to +70°C
Humidity: 95%

Environmental Compliance

UL2043

Power Specifications

IEEE 802.3af PoE Power

Power Options

Power Draw: Typical 10.5W, Max 12.9W
802.3af / 802.3at (PoE/PoE+)

Mounting

Desktop
Wall Mount
Ceiling Tile flush 15/16”
Ceiling Tile Recessed 15/16”, 3/8”, 9/16” sold as an accessory
Ceiling Tile Flush 3/8”, 9/16” sold as an accessory
- Suspend Mount sold as an accessory
